เครื่องตรวจเช็คสีความแม่นยำสูง เครื่องวัดเฉดสี เครื่องวัดสี มิเตอร์เช็คสี DS-210 Precision Colorimeter, Sensor Japan, Chip from USA รับประกัน 1 ปี (สินค้า Pre-Order)

>> แจ้งความต้องการสินค้า <<

หมายเหตุ : กรณีสินค้ามีการอัพเกรดเทคโนโลยีให้ทันสมัยขึ้น ซึ่งบางครั้งอาจเกิดขึ้นได้ โดยที่อาจมีการเพิ่มฟังก์ชั่นมากขึ้นแต่ยังคงฟังก์ชั่นพื้นฐานเดิมไว้ ลูกค้าโปรดยอมรับการเปลี่ยนแปลงที่เกิดขึ้น

Colorimeter is widely used in different industries such as plastic, printing, paint, textile,dyeing,etc. It measures the sample color values of L*a*b*, L*c*h*, color difference ΔE and ΔLab according to CIE color space.

Features:

• Dual optical path design improves repeatability accuracy dE*ab≤0.03
• Over 30 Measurement Indicators
• Evaluate whether the color is jumping light, and provide nearly 40 evaluation light sources
• Contains SCI measurement mode
• Contains UV for fluorescent color measurement
• Calibration base and zirconium reference with a Mohs hardness of 9 to calibrate the instrument, ensuring long-term stability
• The DS-200 series supports 3 measuring apertures for selection(11mm,6mm,3mm)
• Rotate to switch the caliber. Say goodbye to the tedious manual screw fixing method.
• Built-in HD camera for clear observation of the measured area
• Support WeChat applet, Android, Apple, Hongmeng mobile APP
• Use the powerful PC-based colour management system ColorExpert

Function difference:

• Model: DS-210
• Test condition: SCI
• Repeatability: ≤ 0.03
• Aperture: 2
• Camera function: √
• Mobile App: √
• PC software: √

Technical Parameter:

• Product model: DS-210
• Measuring structure: D/8,SCI
• Measurement repeatability: ΔE*ab≤ 0.03
• Display accuracy: 0.01
• Measuring aperture: Φ11mm,Φ6mm
• Color Spaces: Reflectance, CIE-Lab, CIE-LCh, HunterLab, CIE Luv, XYZ, Yxy, RGB, Color
• and Indices:
  • difference(ΔE*ab, ΔE*cmc, ΔE*94,ΔE*00),WI(ASTM E313-00,ASTM  E313-73,CIE/ISO,
  • AATCC, Hunter, Taube Berger Stensby), YI(ASTM D1925,ASTM E313-00,
  • ASTM E313-73), Blackness(My,dM),Color Fastness
• Source condition: A, B, C, D50, D55, D65, D75, F1, F2, F3, F4, F5, F6, F7, F8, F9, F10, F11, F12, CWF, U30, U35, DLF, NBF, TL83, TL84, ID50, ID65, LED-B1, LED-B2, LED-B3, LED-B4, LED-B5, LED-BH1, LED-RGB1, LED-V1, LED-V2
• Light source: LED
• Measurement observation method: Camera
• Calibration: Auto calibration
• Software support: Andriod,iOS,Windows, Wechat app
• Guaranteed accuracy: Guaranteed first class measurement
• Observer: 2°,10°
• Integrating sphere diameter: 40mm
• Standards: CIE No.15,GB/T 3978,GB 2893,GB/T 18833,ISO7724-1,ASTM
• E1164,DIN5033 Teil7
• Ways of spectral: Nano-integrated spectral devices

• Sensor: Silicon photodiode array Dual 16-group

• Wavelength interval: 10nm

• Wavelength range: 400-700nm
• Reflectance determination range: 0-200%
• Reflectance resolution: 0.01%
• Measurement method: Single measurement, average measurement (2 to 99 measurements)
• Measurement time: Approx. 1 second
• Interface: USB, Bluetooth
• Screen: Screen Full colour screen, 2.4
• Battery capacity: 8000 continuous measurements on a single charge, 3.7V/3000mAh
• Life of light: 10 years and 1 million cycles
• Language: Simplified Chinese, English
• Storage: Instrument :10,000 data  ; APP: mass storage

รับประกันสินค้า 1 ปี
