เพาเวอร์ซัพพาย แหล่งจ่ายไฟ Power Supply 12V 5A 60W Waterproof Series TAF-A1260E ประกัน 1 ปี

เพาเวอร์ซัพพาย แหล่งจ่ายไฟ Power Supply 12V 5A 60W Waterproof Series TAF-A1260E ประกัน 1 ปี

>> เช็คสต๊อคสินค้า <<

Feature

• 100% full-load
• Natural air cool
• IP67 Waterproof grade
• Universal input AC input,full range
• Protection: short-circuit, overload, over voltage and over heat

Output

• DC Voltage (V): 12V
• Voltage Range: +/- 5%
• Rated Current (A): 5A
• Current Range (A): 0 - 5A
• Rated Power (W): 60W
• Ripple & Noise (Mvp-p): 100mVP-P
• voltage accuracy: +/- 1%
• Start and Rise Time: 800ms,50ms full load
• Hold Time ( Typ): ≥25ms full load
• Output cables Black cable: for LED cathode , Red cable: for LED positive poles

Input

• Voltage Range (V): 110 ~ 240VAC
• AC Current (A): 1.2A/0.6A
• Frequency Range (Hz): 47 ~ 63Hz
• Power Factor (Typ): PF ≥ 0.50
• Efficiency (Typ): ≥ 83%
• Input cables: Brown cable: "L" Blue cable: "N" Yellow-green cable: " ground"

Protection

• Overload Protection 110-150% rated output power
• Protection type: hiccup,automatic restoration after abnormity remove
• short circuit protection:
• protection when the output is short circuit
• Protection type: hiccup, automatic restoration after abnormity remove

Environment

• Working Temp: 0 ~ 50
• Working Humidity: 20 ~ 90% RH, non-condensing
• Storage Temp& Humidity: 20 ~ 85 , 10% ~95% RH

Others

• Dimensions: 170x52x32 mm (L*W*H)
• Weight: 0.85kg

Remark

1. Unless otherwise specified,all data are take under 230VAC input,rated load and environment temp25
2. Ripple & Noise : measured with a 12" twisted pair cable, terminals in parallel with a 0.1uF and a 47uF capacitor,and on 20MHz bandwidth

รับประกันสินค้า 1 ปี
